| TECHNICAL SPECIFICATION |
| ENGINE | “H-SERIES” BS III |
| MAXIMUM POWER | 160 HP @ 2400 RPM |
| MAXIMUM TORQUE | 550 NM @ 1500 – 1700 RPM |
| CLUTCH | 14” DIA CLUTCH WITH ORGANIC LINING AND MECHANICAL ACTUTATION |
| FRAME | 228 X 75 X 6.15 MM BOLTED LADDER FRAME WITH 6 CROSS MEMBERS |
| FRONT AXLE | NON DRIVEN, I SECTION REVERSE ELLIOT TYPE |
| REAR AXLE | 1616 XL – FULLY-FLOATING SINGLE-SPEED HYPOID WITH 5.83 RAR |
| SUSPENSION | FRONT AND REAR: SEMI – ELLIPTIC, MULTI – LEAF |
| BRAKES | FULL AIR-DUAL LINE BRAKES |
| PARKING BRAKES | FLICK – VALVE OPERATED PNEUMATIC ON REAR WHEELS ONLY |
| BATTERY | 24V (2 X 12) SINGLE POLE; 110 AH |
| FUEL TANK | 165 L CIRCULAR METALLIC TANK |
| TYRES | 10 X 20 – 16PR NYLON – PLY |
| GVW | 10,900 KGS |
| MAJOR DIMENSION (IN MM) |
| | 1616 XL |
| WHEEL BASE | 3607 |
| OVERALL LENGTH (COWL CHASIS) | 5964 |
| OVERALL WIDTH | 2432 |
| FRONT OVERHANG (WITH BUMPER) | 1468 |
| REAR OVERHANG (COWL CHASIS) | 889 |
| FRONT TRACK | 1978 |
| REAR TRACK | 1816 |
| MIN. TURNING – CIRCLE RADIUS | 7050 |
| MIN. GROUND CLEARANCE | 253 |
| WEIGHTS (KGS) |
| | UN – LADEN | LADEN |
| FRONT | 2500 | 6000 |
| REAR | 1740 | 10200 |
| TOTAL | 4240 | 16200 |
| PERFORMANCE |
| | 1616 XL |
| MAXIMUM SPEED IN TOP GEAR | 93 KMPH |
| MAXIMUM GRADEABILITY | 28% |
