| SPECIFICATION | LE | LS | |
| ENGINE | |
| ENGINE | 1.5L TDCR ENGINE(BS-3 & BS-4) |
| TYPE | TURBO-CHARGED DIESEL COMMON RAIL(TDCR) ENGINE |
| DISPLACEMENT/CUBIC CAPACITY | 1,487 CC |
| MAXIMUM POWER@RPM | 58 HP(42.51KW)@3,300 RPM |
| MAXIMUM TORQUE@RPM | 157.5 NM(16.1 KG-M)@ 1,600-2,400 RPM |
| | |
| CLUTCH | 215 MM DIAMETER, DIAPHRAGM,SINGLE DRY PLATE, POT TYPE |
| | |
| TRANSMISSION | |
| TYPE/NO OF GEARS | FULLY SYNCHROMESH 5-SPEED GEARBOX WITH OVERDRIVE(5 FORWARD+1 REVERSE GEARS) |
| GEARS SHIFTING | CABLE TYPE |
| | |
| BRAKES | |
| TYPE | HYDRAULIC VACUUM ASSISTED BOOSTER BRAKES WITH LSPV |
| FRONT;REAR | VENTILATED DISC TYPE; DRUM TYPE |
| | |
| SUSPENSION | |
| FRONT | RIGID TUBULAR AXLE WITH PARABOLIC LEAF SPRING |
| REAR | PARABOLIC LEAF SPRING, 2 STAGES, OVERSLUNG |
| TYRES(SIZE/TYPE) | 185 R14 LT, 8PR , RADIAL |
| | |
| WEIGHT | |
| GVW(GROSS VEHICLE WEIGHT) | 2,522 KG |
| KERB WEIGHT(INC. CONTAINER) | 1,362 KG(WITH DRIVER)/ 1,362KG (WITH DRIVER) |
| RATED PAYLOAD(WITH CONTAINER) | 1,160 KG(1.25 TONS)/ 1,160 KG(1.25 TONS) |
| | |
| SEATING CAPACITY | DRIVER+1 |
| | |
| FUEL TANK CAPACITY | 40 LITRES |
| | |
| DIMENSIONS | |
| OVERALL VEHICLE LENGTH | 4,485MM |
| OVERALL VEHICLE WIDTH | 1,620MM |
| OVERHALL VEHICLE HEIGHT | 1,868MM |
| WHEELBASE | 2,350 MM |
| LOAD BODY/ CARGO DECK(L X B X H) | 2500MM X 1620MM X 1021MM(8.2FT X 5.3FT X 3.3FT) |
| MINIMUM TURNING CIRCLE RADIUS | 5.85MM |
| GROUND CLEARANCE | 172MM |
| LOADING HEIGHT | 809MM |
| | |
| PERFORMANCE | |
| MAXIMUM SPEED | 90 KMPH |
| MAXIMUM GRADEBILITY | 29%(WITH RATED PAYLOAD) |
