| TECHNICAL SPECIFICATION |
| ENGINE | “H-SERIES”, 4 CYCLINDER INLINE PUMP |
| MAXIMUM POWER | 120 HP @ 2400RPM |
| MAXIMUM TORQUE | 392 NM @ 1600 RPM |
| CLUTCH | 330 MM DIA SINGLE PLATE DRY TYPE-HYDRAULIC ACTUTATION |
| GEAR BOX | SYNCHROMESH 6S ODGB WITH FGR 8.2:1 |
| FRAME | ALL STEEL LADDER TYPE WITH BOLTED CONSTRUCTION |
| FRONT AXLE | I SECTION REVERSE ELLIOT |
| REAR AXLE | FULLY FLOATING 60SHO 5.57:1 RAR |
| SUSPENSION | SHACKLE ENDED |
| CABIN | ALL STEEL FACTORY BUILT TILTABLE DAY CABIN |
| STEERING | POWER STEERING |
| BRAKES | FULL AIR-DUAL LINE S-CAM BRAKES |
| PARKING BRAKES | SPRING ACTUATED, PNEUMATIC (ON REAR ONLY) |
| BATTERY | 12 V-100 AH |
| FUEL TANK | 212 LTS (115 LTS FOR 2850 MM WB) |
| TYRES | 9.00 X 20 – 16PR RADIAL OPTION |
| GVW | 14600 KGS |
| MAJOR DIMENSION |
| WHEEL BASE | 4200 – DAY | 4750 – DAY | 4750 – SLEEPER |
| FRONT/REAR OVERHANG (MM) | 1338/2125 | 1338/2470 |
| OVERALL LENGTH | 7663 | 8558 |
| OVERALL WIDTH | 2307 |
| TURNING CIRCLE CLEARANCE DIA | 14500 | 16300 | 16300 |
| FRONT TRACK/REAR TRACK | 1964/1816 |
| LOAD BODY LENGTH | 19 FT | 22FT | 20FT |
| LOAD BODY INTERNAL WIDTH | 7’6” |
