3532 Series – 8x4 Tippers
The 3532 Series (TN variant) is built for tough mining and construction work. It comes with a powerful 320 HP BS-VI engine and 1200 Nm torque, giving strong performance even on rough terrain. Designed for high productivity, it helps complete trips faster, reduces downtime, and lowers overall operating costs, making it a reliable choice for heavy-duty operations.
Key Features
Superior Mileage
- Fuel-Smart Long Haul
- Max Savings Guaranteed
- Heavy-Duty Efficiency
Best-in-Class Performance
- Power When Needed
- Smooth Heavy Acceleration
- All-Terrain Consistency
Enhanced Cabin Comfort
- Driver-First Ergonomics
- Fatigue-Free Long Drives
- Comfort Built In
Driver Comfort & Safety
- Comfortable driver cabin
- Better visibility access
- Reliable braking safety
Lower Maintenance Cost
- Low maintenance cost
- Easy service support
- Maximum business uptime
Strong After-Sales Support
- Strong after-sales support
- Authorized service center
- Professional maintenance service
Product Specification
| Specification | Detail | ||
|---|---|---|---|
| Engine Type | A-Series, BS-VI 6 cylinder with i-Gen6 technology | ||
| Engine Power | 240 kW @ 2200 rpm (320 hp) | ||
| Engine Torque | 1200 Nm @ 1100 - 1900 rpm | ||
| Clutch | 430 mm, Single dry plate, Organic clutch, Air assisted Hydraulic Booster | ||
| Gearbox | 9 speed DD gearbox with crawler gear, FGR 8.83:1 | ||
| Rear Axle Type & RAR | Hub reduction axle with RAR 7.2:1 | ||
| Fuel Tank Capacity | 300 L | ||
| DEF Capacity | 24 L | ||
| Electricals | 24 V - 120 Ah (150 Ah for N Cabin) | ||
| Max Speed | 60 kmph | ||
| Gradeability | 48.1% | ||
| Turning Circle Dia | 18.94 m | ||
| Frame Dimensions | 275 mm x 75 mm x 8 mm with 6 mm flitch | ||
| Front Suspension | Parabolic leaf spring with shock absorbers and anti-roll bar | ||
| Rear Suspension | Inverted semi elliptical tandem, HD bogie, 1500 mm Span | ||
| Cabin Options | Tiltable day, front pivoted rear suspended, with AC Cabin | ||
| Brakes | 10 bar system, drum brakes | ||
| Front Axle | 10T Zero Drop axle | ||
| Tyres | 12x20 ML, 12x24 ML, 11x20 ML (Optional) |
| Parameter | Option 1 | Option 2 | Option 3 |
|---|---|---|---|
| Wheelbase | 5250 mm | 5250 mm | 5250 mm |
| Body Capacity |
23 Cum Box |
19 Cum Rock |
26 Cum Box |
